Automatic transfer switch

Model Number : AZ2R

Certification : CE

Place of Origin : China

MOQ : 5pcs

Payment Terms : T/T

Contact Now

AZ2R-63

automatic transfer switch is a PC class infrequent change-overswitch,with two-station design (commonly used for A and standby for B)suitable for AC systems with AC 50-6Ohz and rated current 6A-63A.The main function of the automatic transfer switch is when the main power

(common power supply A) fails,the ATS will automatically switch to the backup power (Backup power supply B) to continue working (switching speed <50 milliseconds),which can effectively solve the troubles caused by power outages.

Automatic transfer switch

Automatic transfer switch Images
